Parameter Information
|
Brand name |
Internal tooth lock washer/external tooth lock washer |
|
Standard |
Internal teeth GB861.1/ external teeth GB862.1 |
|
Category |
Lock washer |
|
Wood quality |
304 stainless steel |
|
Standard type |
National standard |
|
Surface treatment |
Stainless steel washing |
|
Packaging |
Packaging bag + carton packaging |
Specification
|
Specification (large diameter of thread) |
d |
D |
s |
Number of teeth |
The weight of every 1000 steel products is ≈kg |
||
|
min |
max |
min |
max |
min |
|||
|
2 |
2.2 |
2.45 |
4.2 |
4.5 |
0.3 |
6 |
0.2 |
|
2.5 |
2.7 |
2.95 |
5.2 |
5.5 |
0.3 |
6 |
0.3 |
|
3 |
3.2 |
3.5 |
5.7 |
6 |
0.4 |
6 |
0.4 |
|
4 |
4.3 |
4.6 |
7.64 |
8 |
0.5 |
8 |
0.10 |
|
5 |
5.3 |
5.6 |
9.64 |
10 |
0.6 |
8 |
0.18 |
|
6 |
6.4 |
6.76 |
10.6 |
11 |
0.6 |
8 |
0.21 |
|
8 |
8.4 |
8.76 |
14.6 |
15 |
0.8 |
8 |
0.47 |
|
10 |
10.5 |
10.93 |
17.6 |
18 |
1 |
9 |
0.80 |
|
12 |
12.5 |
12.93 |
20 |
20.5 |
1 |
10 |
1.12 |
|
14 |
14.5 |
14.93 |
23.5 |
24 |
1.2 |
10 |
1.69 |
|
16 |
16.5 |
16.93 |
25.5 |
26 |
1.2 |
12 |
2.10 |
|
18 |
19 |
19.52 |
29.5 |
30 |
1.5 |
12 |
3.14 |
|
20 |
21 |
21.52 |
32.4 |
33 |
1.5 |
12 |
3.80 |
|
Specification (large diameter of thread) |
d |
D |
s |
Number of teeth |
The weight of every 1000 steel products is ≈kg |
||
|
min |
max |
min |
max |
min |
|||
|
2 |
2.2 |
2.45 |
4.2 |
4.5 |
0.3 |
6 |
0.2 |
|
2.5 |
2.7 |
2.95 |
5.2 |
5.5 |
0.3 |
6 |
0.2 |
|
3 |
3.2 |
3.5 |
5.7 |
6 |
0.4 |
6 |
0.4 |
|
4 |
4.3 |
4.6 |
7.64 |
8 |
0.5 |
8 |
0.9 |
|
5 |
5.3 |
5.6 |
9.64 |
10 |
0.6 |
8 |
0.18 |
|
6 |
6.4 |
6.76 |
10.6 |
11 |
0.6 |
8 |
0.19 |
|
8 |
8.4 |
8.76 |
14.6 |
15 |
0.8 |
8 |
0.54 |
|
10 |
10.5 |
10.93 |
17.6 |
18 |
1 |
9 |
0.92 |
|
12 |
12.5 |
12.93 |
20 |
20.5 |
1 |
10 |
1.09 |
|
14 |
14.5 |
14.93 |
23.5 |
24 |
1.2 |
10 |
1.94 |
|
16 |
16.5 |
16.93 |
25.5 |
26 |
1.2 |
12 |
2.07 |
|
18 |
19 |
19.52 |
29.5 |
30 |
1.5 |
12 |
3.66 |
|
20 |
21 |
21.52 |
32.4 |
33 |
1.5 |
12 |
4.34 |
