Parameter Information
|
Brand name |
Big hexagon flange bolt |
|
Standard |
GB5789 |
|
Wood quality |
316L stainless steel |
|
Product strength |
Other |
|
Head shape |
Outer hexagon |
|
Standard type |
National standard |
|
Surface treatment |
Stainless steel washing |
|
Packaging |
Packaging bag + carton packaging |
Specification
There are tolerances in this product, the size is subject to the actual object, please be careful to shoot!
Size unit: mm
|
d |
|
M5 |
M6 |
M8 |
M10 |
M12 |
M14 |
M16 |
M20 |
|
dc |
max |
11.8 |
14.2 |
18.0 |
22.3 |
26.6 |
30.5 |
35.0 |
43.0 |
|
ds |
max |
5 |
6 |
8 |
10 |
12 |
14 |
16 |
20 |
|
min |
4.82 |
5.82 |
7.78 |
9.78 |
11.73 |
13.73 |
15.73 |
19.67 |
|
|
e |
min |
8.56 |
10.8 |
14.08 |
16.32 |
19.68 |
22.58 |
25.94 |
32.66 |
|
k |
max |
5.40 |
6.60 |
8.10 |
9.20 |
10.40 |
12.40 |
14.10 |
17.70 |
|
s |
max |
8 |
10 |
13 |
15 |
18 |
21 |
24 |
30 |
|
min |
7.64 |
9.64 |
12.57 |
14.57 |
17.57 |
20.16 |
23.17 |
29.16 |
